COIL ANNEALING FURNACE

COIL ANNEALING FURNACE

Annealing - a type of heat treatment of metals and alloys, comprising heating to a certain temperature, aging and then, usually, slow cooling. The purpose of annealing is to eliminate arising in the metal structure during molding, pressure treatment, welding deviations from the equilibrium state, i.e. Returns the crystal structure and homogenization. Annealing is carried out to reduce hardness and enhance treatment ability, improve the structure and achieve uniformity with the elimination of internal stress.

  • Temperature control:high precision control of temperature changes, automatic process of heat treatment. The fan is mounted in the bottom of the furnace to ensure stable heat throughout the entire cooking process and maintain a uniform temperature, temperature accuracy is ± 5 degrees Celsius.
  • Source of heating: Electricity or Natural Gas;
  • Protective atmosphere:of ammonia or endo-gas and nitrogen purified protect steel from oxidation, decarbonization, preventing loss metal;
  • Capacity:8 ~ 36 tons, takes slight party wire (≤ 10 t / party);
  • Easy to use and install:the cover of the furnace is equipped with a pneumatic device opening and closing.
Model-Specification Effective Size Diameter * Height Electric Power Loading capacity
RFG8-200/280 2000*2800H 220 8
RFG8-280/200 2500*2000H 240 8
RFG8-360/200 2800*2000H 360 14
RFG8-360/200 3600* 2000H 500 22
RFG8-360/240 3600* 2000H 580 26
RFG8-360/280 3600*2800H 600 28
RFG8-360/340 3600* 3400H 620 30
